Recreational LED Tennis Court Kit (6 Pole, 6 Fixture)

Description

This LED Tennis Court Lighting Kit is designed with the budget-conscious tennis player in mind. Using a recreational six pole setup, the 78′ x 36′ playing area is evenly lit for backyard and residential use.

Package Includes:

(6) 20’ x 4” x 7G Round Straight Steel Poles & Galvanized Anchor Bolts

(6) 2-3/8” OD Tenon Mount Adaptors

(6) 300W Type IV LED Area Lights

Footcandle Levels:

Average: 29.08

Maximum: 37.70

Minimum: 22.60

Max/Min (Uniformity): 1.67

Fixtures

This Residential LED Tennis Court Lighting Kit comes with (6) LED 300W Type IV Area fixtures. See full specs on the economical court lights below.

System Wattage: 300W

Lumens: 40,646

Color Temperature: 5000K

Expected Life: 100,000 Hours

Driver: 100-277V

Light Distribution: Type IV Tennis Optic that throws the light forward on the court for optimal performance and no light wasted. Photometric data is tested in accordance with IESNA guidelines.

Weight: 29.6 lbs.

Fixture Dimensions: 33.25″ x 14″ x 4.25″in

Warranty: 5-Year Warranty

Listings: UL Listed, IP65 rated

EPA Rating: 1.4

Finish: A powder coat finish that withstands extreme weather changes without cracking or peeling.

Housing: One-piece, die-formed aluminum housing contains a prewired driver in a gasketed, weather-resistant wiring compartment.

Poles

This Residential LED Tennis Court Lighting Kit comes with (6) 20′ round steel poles equipped with anchor bolts and base covers.

Pole Height: 20 ft.

Number of Anchor Bolts: 4 per pole

Pole Diameter: 4”

Features:

POLE ─ The pole shaft is fabricated from hot rolled carbon steel having a minimum yield of 46,000 PSI and conforms to ASTM A500 grade C requirements. The shaft construction is a single piece of formed steel welded longitudinally. The hand hole is located 1’ above the pole base. A ground lug is provided standard.

ANCHOR BASE ─ The anchor base is fabricated from a structural quality hot rolled carbon steel plate that has a minimum yield strength of 36,000 PSI. The anchor base telescopes the pole shaft and has a circumferential weld on the top and bottom.

BASE COVER ─ A full base cover is provided which encapsulates the base plate and anchor bolts to provide a clean transition from pier to pole

Finish – A Super Durable Polyester powder coat finish is electrostatically applied in a state-of-the-art paint facility. Standard colors available: Black or Bronze.

*Galvanizing available for poles upon request*

Mounting

This Residential LED Tennis Court Lighting Kit comes with (6) 2-3/8” OD Mounting Tenons.

Features:

APPLICATION ─ The TVA series of tenon adaptors were designed to adapt an existing straight square or round pole to provide a 2-3/8” OD tenon to allow mounting of a fixture via an adjustable slip fitter (2AF) or additional pole mounting hardware for multiple fixtures.

CONSTRUCTION ─ The heavy duty tenon is constructed of steel tubing. Stainless steel hardware provided.

Lead Time

This Residential 300W LED Tennis Court Lighting Kit typically ships in 3-4 weeks. Anchor bolts pre-shipped upon request. All poles and fixtures included in this package are made to order based upon the specifics listed above.

*Please consult with LED Spot for lead time estimates.
